American Technologies Network has released the ThermoSight T50, a mission-flexible thermal sight that can be utilized as a weapon sight or a handheld rugged imager for scouting, surveillance, or covert operations.
The ThermoSight T50 is compatible with standard day optics such as the Trijicon Advanced Combat Optical Gunsight (ACOG) Model TA31, 4x32 that maintains the boresight even through extensive rounds of firing, field of view and keeps the reticle calibrated. The longwave thermal imaging sensor provides crisp imagery through fog, smoke, dust, to total darkness. The operator friendly sight is lightweight and portable and operates with single-button controls for basic image adjustment. A rubber shroud ensures complete obscurity for covert operations by eliminating illumination of the operator from the viewfinder.
The ThermoSight T50 runs on three CR123 batteries for nine hours continuously.
ATN ThermoSight T50 320x240 Thermal Weapon Sight
THERMAL IMAGING PERFORMANCE
* Sensor type 320 x 240 VOx microbolometer
* Field of view 9.33∞ (h) x 7∞ (v)
* Spectral band 7.5-13.5 ºm
* Automatic features Contrast, brightness, STACETM (digital image enhancement)
SYSTEM FEATURES
* Silent operation, inaudible beyond 1 m
* Boresight adjustment holds boresight through extensive rounds of firing
OUTPUTS
* Built-in video display VGA monochrome and RS-170 output
POWER
* Three CR123 batteries
* Battery life approximately nine hours continuous use
ENVIRONMENTAL
* IP rating - IP 68
* Operating temp -40∞C to +75∞C (-40∞F to +131∞F)
* Storage temp -50∞C to +85∞C (-58∞F to +149∞F)
DIMENSIONS, WEIGHT, and MOUNTING
* Dimensions (lens covers off) 5.3 L x 3.5 W x 4.0 H
* Weight 24 oz with batteries, lens covers and rail mount
* Mounting Picatinny rail mount
INTERFACES
* Command and control auto/manual gain/level, polarity, manual NUC, 2x, 4x digital zoom
STANDARD PACKAGE
* Laser pointer 30 mW @ 850 nm and safety mode of 0.5 mW
* Batteries 3 each, CR123, fit into plastic sleeve for quick removal and replacement
* Price: $9,956
